16 Channel RTD Temperature Input Module
Product No.: ZH-T16PT100
16 RTD temperature input channels
Supports PT100, PT1000, Cu50 and Cu100 sensors
Independent channel configuration
Temperature range:-200-+800
The ZH-T16PT 16 Channel RTD Temperature Input Module is a high-performance industrial temperature data acquisition device designed for precise multi-point temperature monitoring. It supports PT100, PT1000, Cu50, and Cu100 RTD sensors, making it suitable for industrial automation, process control, power systems, HVAC, laboratory equipment, and energy management applications.
The module features 16 independent RTD input channels, supports RS485 and Ethernet communication, and is fully compatible with Modbus RTU and Modbus TCP protocols for seamless integration with PLCs, SCADA systems, HMIs, and Industrial IoT platforms.
Why Choose ZH-T16PT?
1.16 Independent RTD Inputs
Monitor up to 16 temperature points simultaneously using one compact module, reducing wiring complexity and installation costs.
2.Compatible with Multiple RTD Sensors
Supported sensor types include:PT100,PT1000,Cu50,Cu100
Each channel can be configured independently to match different RTD sensor types.
3.Industrial Communication
Communication options include:RS485,Ethernet
Supported protocols:Modbus RTU,Modbus TCP
The Ethernet version supports industrial networking for PLC, SCADA, HMI, BMS, and EMS integration.
4.Flexible Network Functions
The Ethernet version supports:TCP Server,TCP Client,UDP Server,UDP Client,DHCP,DNS,AUTO-MDIX,Virtual COM Port
Suitable for remote monitoring and Industrial IoT deployments.
Key Features
1.16 RTD temperature input channels
2.Supports PT100, PT1000, Cu50 and Cu100 sensors
3.Independent channel configuration
4.Per-channel temperature compensation
5.High-precision temperature acquisition
6.RS485 communication
7.Ethernet communication (optional models)
8.Supports Modbus RTU and Modbus TCP
9.DIN rail installation
10.Wide DC power supply
11.Industrial EMC design
12.Stable long-distance communication
13.Compatible with PLC, SCADA, HMI and Industrial IoT systems
Technical Specifications
Item
Specification
Input Channels
16 RTD Inputs
Temperature range
-200-+800
Sensor Types
PT100, PT1000, Cu50, Cu100
Communication
RS485 / Ethernet
Protocol
Modbus RTU / Modbus TCP
Temperature Compensation
Independent per Channel
Mounting
DIN Rail
Power Supply
DC Wide Voltage Input
Applications
Industrial Temperature Monitoring
The module supports easy integration with industrial automation systems through standard communication protocols.
Supported communication:Modbus RTU,Modbus TCP
Compatible systems:PLC,SCADA,HMI,Industrial PC,Edge Gateway,Building Management System (BMS),Energy Management System (EMS)
The Ethernet version supports multiple networking modes, including TCP Server, TCP Client, UDP Server, UDP Client, DHCP, DNS, Virtual COM Port, and AUTO-MDIX, providing flexible deployment in industrial Ethernet environments.
Typical Applications
The ZH-T16PT is suitable for:
*Industrial automation
*Factory temperature monitoring
*HVAC systems
*Boiler monitoring
*Heat treatment equipment
*Food processing
*Pharmaceutical production
*Chemical process control
*Energy management systems
*Smart factories
*Laboratory equipment
*Environmental monitoring
*Power distribution cabinets
*Data centers
*Industrial IoT
Ordering Information
FAQ
Model
Communication
ZH-T16PT-14
RS485
ZH-T16PT-34
Ethernet + RS485
The module supports PT100, PT1000, Cu50, and Cu100 RTD temperature sensors.
2.Can each channel be calibrated individually?
Yes. Each channel supports independent temperature compensation, allowing users to correct measurement deviations for individual sensors.
3.Does the module support Ethernet?
Yes. The Ethernet version supports Modbus TCP communication as well as TCP Server, TCP Client, UDP Server, UDP Client, DHCP, DNS, Virtual COM Port, and AUTO-MDIX networking features.
4.Is the module compatible with PLC systems?
Yes. It supports Modbus RTU and Modbus TCP, making it compatible with most PLCs, SCADA software, HMIs, and Industrial PCs.
5.Can the communication protocol be switched?
Yes. The communication mode can be configured between Modbus RTU and Modbus TCP through the communication registers.
