16 Channel Industrial DC Voltage Current Monitoring Module

16 Channel Industrial DC Voltage Current Monitoring Module

Product Overview

The ZH-44163 series is a professional industrial-grade 16-channel fully isolated DC acquisition module designed for high-precision voltage and current monitoring applications.

Each channel adopts an independent differential input architecture with complete isolation between channels. Power supply isolation, communication isolation, and signal isolation are fully implemented to ensure excellent anti-interference performance in harsh industrial environments.

The module integrates a high-performance 32-bit ARM industrial MCU together with a 24-bit high-resolution ADC, enabling high-speed synchronized sampling with exceptional measurement accuracy and stability.

It is widely used in:

1.Energy storage systems

2.Battery testing equipment

3.Industrial automation

4.Electrical monitoring systems

5.Photovoltaic systems

6.New energy equipment

7.Data acquisition systems

8.Process control systems

Full Isolation Design

The module adopts complete electrical isolation technology:

1.Channel-to-channel isolation

2.Signal isolation

3.Power isolation

4.Communication isolation

This design significantly improves:

1.System reliability

2.EMC performance

3.Surge resistance

4.Industrial noise immunity

5.Isolation withstand voltage exceeds 2500VDC.

High-Precision Measurement

The module uses industrial-grade 24-bit ADC chips to achieve:

1.Accuracy up to 0.1%

2.Linear accuracy better than 0.05%

3.Resolution up to 1/100000

Communication Interface

The module supports:

RS485 Communication

--Modbus-RTU protocol

Ethernet Communication

--RJ45 Ethernet interface

--Modbus-TCP protocol

Communication baud rate supports:

2400 / 4800 / 9600 / 19200 / 38400 / 57600 / 115200bps

Industrial Applications

This module is widely used in:

1.Energy storage battery monitoring

2.Industrial automation systems

3.DC signal monitoring

4.Battery pack testing

5.Power supply monitoring

6.Electrical control cabinets

7.Industrial process monitoring

8.New energy systems

9.Smart manufacturing systems

Key Features

1.16-channel fully isolated DC signal acquisition
2.Independent differential input for each channel
3.24-bit high-precision ADC sampling
4.Accuracy up to 0.1%
5.Linear accuracy better than 0.05%
6.Resolution up to 1/100000
7.RS485 or Ethernet communication optional
8.Supports Modbus-RTU and Modbus-TCP
9.Adjustable gain: 1x / 2x / 4x / 8x
10.Industrial 32-bit ARM MCU
11.Maximum value detection and hold function
12.Wide power supply range: 9-30VDC or 9-55VDC
13.2500VDC isolation protection
14.DIN rail mounting support

Product Models

ZH-44161-14F2/#V:16-Channel Fully Isolated DC Voltage Acquisition Module(9–30VDC Power Supply, RS485 Communication)
ZH-44161-34F2/#V:16-Channel Fully Isolated DC Voltage Acquisition Module(9–30VDC Power Supply, Ethernet Communication)
ZH-44162-14F2/#A:16-Channel Fully Isolated DC Current Acquisition Module(9–30VDC Power Supply, RS485 Communication)
ZH-44162-34F2/#A:16-Channel Fully Isolated DC Current Acquisition Module(9–30VDC Power Supply, Ethernet Communication)
ZH-44163-14F2/#V#A*:16-Channel Fully Isolated DC Voltage & Current Combination Acquisition Module(9–30VDC Power Supply, RS485 Communication)
ZH-44163-34F2/#V#A*:16-Channel Fully Isolated DC Voltage & Current Combination Acquisition Module(9–30VDC Power Supply, Ethernet Communication)

Technic Specification

FAQ

Does the module support Modbus TCP?

Yes. Ethernet versions support Modbus-TCP communication.

Is channel-to-channel isolation supported?

Yes. Each channel is independently isolated.

What is the ADC resolution?

The module uses a 24-bit high-precision ADC.

Can the module measure both voltage and current?

Yes. Combination models support mixed voltage/current input.

What industries is this product suitable for?

Energy storage, industrial automation, battery testing, electrical monitoring, and photovoltaic systems.
